heroal D 92 UD

The variable and efficient front door system

The heroal D 92 UD front door system is characterised by intuitive operation and adaptive design. The system offers a multitude of design options with its modular structure. The appearance and usage properties can be easily adapted to different capabilities or new user requirements. And this has no effect whatsoever on the outstanding performance features or functional operability.

Innovative reversible infill panel attachment and side section integration
With its heroal D 92 UD door system, heroal is providing innovative infill panel attachment for aluminium materials. This variant offers the possibility of fixing the prefabricated infill panel in the casement by means of joints. Due to the different possibilities provided by the heroal infill panel attachments, maximum casement leaf sizes can be manufactured. Processors are offered many benefits as the heroal D 92 UD door system can be extended thanks to a profile design for this type of infill panel attachment. Easy installation, even at the construction site, reversible for Design modifications and time-saving processing of the entire system are just a few aspects of the new design.

Creative diversity
By extending the profiles for the connection of side sections from the heroal D 92 UD front door system, heroal is providing processors with new opportunities. Depending on your requirements, side sections can be finished with surrounding frames or with adjoining side sections. This provides new possibilities for the design of side sections, e.g. matching finishes for both the casement and the side section. Optionally, the processor can choose the best suited variation of processing. heroal offers the expected short and simple processing times for the new design of the side sections.


Cross section

System dimensions

Profile depth [mm]

Frame profile
85 - 120
Leaf profile
78 - 92
Bar profile
92

Visible profile width [mm]

Frame profile
85 - 120
Leaf profile
56 - 85
Bar profile
94 - 120

System properties

Glass filling strength [mm]
92
Max. leaf weight [kg]
180
Max. leaf widths [mm]
1.400
Max. leaf heights [mm]
2.500

Performance characteristics

>1,3 Thermal insulation [Uf in W/m2K] / Profile width [mm]
4 Air permeability
>0,70* Heat insulation (UD in W/m2K) / Profile width [mm]
9A Resistance to driving rain
C5 Wind resistance
1-3 Soundproofing class
RC 3 Resistance to burglary
2 Operating forces
Impact resistance
3 Mechanical resistance
Load-bearing capacity of safety equipment
6 Continuous function

* UD value according to DIN EN 10077-1, calculated based on element size 1230 x 2180 mm

!) Application-specific special approvals for oversized elements from heroal
